TopMatrix ® technology
Worldwide Patented Innovation
Dies including this technology are all
named TopMatrix®
dies, or TOPMATRIX® dies or
topmatrix® dies.
Most often, TopMatrix® dies are requested
by big buyers
of corrugated packages, in a deal with the actual diecutting plant,
to secure that they always get best possible cut quality supplied,
i.e. minimum of strip fails, swarf/dust, cracks etc. But most often
also requested as a part of a productivity program, focused on all
those very dies in a plant which are in use very often, in order
to get great savings, on set times, number of needed renewal dies
or knife/rubber repairs etc.
|
This is how TopMatrix® technology
works !
Red parts are CAD/CAM-made plates, laminated/glued to the ejection rubber,
overall the cut layout or partially only, due to required functions and die-tool economy.
|
|
”overall/full design”
= normal on flatbed dies |
”partial design”
= normal on rotary dies |
The plates have slippery stiff and hydrophobic surfaces, and all extends close up to
the steel rules(cut/creasing) (in the figures: black vertical bars)
The resulting die, works as any other type of die in die-cutting machines, but performs
in a much superior way, due to the slippery surfaces, edges etc., which effectively,
-
synchronize the compression as well as the ejection, close up to the steel rules,
although uneven anvils are used or uneven corrugated boards are processed.
-
eliminate locking/tearing/cracking forces against the corrugated board, especially
if stiff, fast ejectors are used and if high speed is applied
-
eliminate local crushes of the corrugated board, especially if stiff or fast ejectors
are used
-
stabilize the cutting/nip zones from being forced aside during the cut moment
and prior full split is accomplished
|
|
|
Commercial availability and license
Can be used by licensed plants only, or by such plants which
are supplied by a licensed diemaker, please contacts us for
details.
Illegal use by a diecutting plant is a serious crime, associated
with penalty fees, bad publicity etc, with ref. to both international
and national laws.
|
PCT appl. SE90-40/SE00-290/SE02-
1466, both pending, granted patents and registered
trade names, e.g.
EUROPE/EU1432558; 1202859;
0454753: Austria, Belgium, Switzerland, Czechia, Denmark,
Germany, Spain, Finland, Italy, France, Great Britain, Ireland,
Lichtenstein, Netherlands, Portugal, Slovakia, Sweden;
NORWAY 330268;
USA 8,757,037 B2
CANADA 2471323;
AUSTRALIA 022334496; 634206;
NEW ZEALAND 533573; 515425;
JAPAN 2795417; et al
All patents are managed by the
inventor Prof. Dr. Sören Cavlin
and the holding company SOBI. |
|
|
